WTSSDG-09
Product Information
This model is the standard duty workhorse that supports gas arc stud welding. It is suitable for 1/2' (13mm) weld studs all day long. The internal weld cable makes for a compact, ergonomic unit. The construction is rugged, glass filled nylon. Unlike competitive units which are thermo set plastic the glass filled nylon with stands the most rugged environments. The heavy 3/16 (4.5mm) wall thickness means this gun can endure the most harsh shops. Image arc guns use a unique ball bearing clutch lift system. Competitive guns use a "hook and lock ring" lift mechanism. This hook and ring induces rotation into the gun. The Image lift system locks in a linear fashion to keep unwanted rotation out of the gun. The foot for the gas arc is aluminum for the higher temperature and duty cycle of gas arc stud welding. All these design extras mean a long life tool to provide many years of reliable service.
Stocked: Yes
Documents
Standard Duty (1/2") Drawn Arc Stud Gun Specification SheetStandard Duty (1/2") Drawn Arc Stud Gun User Manual
Standard Duty (1/2") Drawn Arc Stud Gun Exploded Diagram
